Grimsby Turkish Baths:
plan and cross-section of the new baths, 1891
Plan of the Grimsby Turkish bath


Plan of the building work to be undertaken

for the Grimsby Turkish & Hydropathic Baths Co Ltd in 1891



Cross-section of the Grimsby Turkish bath


Cross-section of the building  at A—B in the above plan.

John J Cresswell, Architects, Grimsby



< Both illustrations reproduced from: 'Grimsby Turkish Baths'    The Building news    (11 September 1891)

This page enlarges an image or adds to the information found on the following page:

Grimsby Turkish Baths
